Specifications
1. Sterilizer bottle and cap after filling
2.Capacity 1000-15000bph
3.Time 15-20s
4.CE, ISO certification
Machine advantage:
1. Bottle overturn 90 degree or 110 degree.
2. The sterilizing time is adjustable.
3. Our company have passed CE, ISO certification
Charactistic:
1.It is mainly used after hot filling fruit juice and tea in PET bottle to sterilize PET bottle mouth and inside surface of caps,which haven't been disinfected by high temperature .
2.It mainly consists of chief conveying chain system ,surport ,bottle reversing chain system ,bottle reversing guiding rod and bottle repositioning rod .
3.It uses inner thermal medium to disinfect bottle mouth and caps without any other heat source,so it can save energy.
4.The machine is fully made of SUS304 stainless steel ,elegant in appearance more convient in operation.
Mian technical parameters:
|
Model
|
Production capacity
|
Bottle reversing time
|
Belt speed(m/min)
|
Power
|
|
DP-8
|
3000-8000(b/h)
|
15-20s
|
4-20
|
3.8kw
|
|
DP-12
|
8000-15000(b/h)
|
15-20s
|
4-20
|
5.6kw
|
